Maxbright Display Media (Shenzhen) Co.,Ltd.
| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | Maxbright |
| Certification: | CE |
| Model Number: | T550EDCP-DF |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Pearl cotton shock absorption + carton + pallet packaging |
| Delivery Time: | 4~5 week |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50-100 unit / month |
| Product Name: | 55 Inch High Bright Double Sided Outdoor LCD Digital Signage Totem | Screen Size: | 55" Dual Face |
|---|---|---|---|
| Resolution (pixel): | 1080 X 1920 RGB, 3840 X 2160 RGB(4K) Model Available | Brightness: | 2500-3000cd/m2 |
| Response Time: | 4.5ms | Pixel Pitch: | 0.63(H) X 0.63(V) Mm |
| Interface: | VGA, HDMI X 2 | Display Area (mm): | 680.4x 1209.6 Mm |
| Touch Screen: | Projected Capacitive Touch G+G 10 Points | ||
| High Light: | 0.630mm Double Sided LCD Display,55 Inch Double Sided Digital Signage,55" 0.630mm LCD Digital Signage |
||
55 inch High Brightness Double Sided Outdoor Street LCD Display
Quick Detail Of Outdoor LCD Digital Signage
1. Professional Outdoor kiosk with excellent design;
2. Industrial level 55” brand new BOE original panel with LED backlight;
3. Fully meet outdoor IP65 usage standard application;
4. 55 Inch High Bright Dual face Outdoor LCD Digital Signage
5. Support industrial level fan ventilating, ensure reliable running;
6. Support anti-reflection glass, make sure best view experience;
7. Support high brightness of 2500-3000 nits, ensure readable under sunlight;
8. Built in auto-temperature control system, can turn off the kiosk automatically while overheat;
9. Intelligent air-looping system, can protect the kiosk panel against the so called “blackout”;
Specification Of Outdoor LCD Digital Signage
| PANEL TYPE | 2 x 55" a-Si active matrix TFT-LCD |
| ACTIVE AREA | 1209.6 x 680.4 mm in portrait orientation |
| NATIVE RESOLUTION | 1080 x 1920 RGB, 3840 x 2160 RGB(4K) model available |
| PIXEL PITCH | 0.630(H) x 0.630(V) mm |
| COLOR | 16.7 Million, 8 bits |
| HORIZONTAL FREQ. | 57.3KHz ~ 70KHz |
| VERTICAL FREQ. | 47Hz ~ 63Hz(DVB/PAL), 57Hz ~ 63Hz(NTSC) |
| BRIGHTNESS | 2500-3000 cd/m2, LED Backlight Enhanced |
| CONTRAST RATIO | 1400:1, Dynamic contrast ratio: 10000:1 |
| DIMMING | Auto-dimming by Light Sensor |
| VIEWING ANGLE | 89/89/89/89 |
| RESPONSE TIME | 4.5ms |
| INTERFACE | VGA,, HDMI x 2 |
| MEDIA PLAYER | Media Player (RK3288 CPU) (option) |
| REMOTE CONTROL | Support for Full OSD Features |
| OPERATING VOLTAGE | AC 100 ~ 240V 60/50Hz |
| POWER CONSUMPTION | 2500-3000 nits: 900W~1000W for two panels |
| STANDBY MODE | 10 Watt or less |
| ACCESSORIES | AC Power Cord, Remote Controller |
| HDMI, VGA cable x 2 | |
| OPERATING | Mini PC: i5-6500 CPU 3.2GHz, 4-8GB DDR2 |
| (option) | 128G SSD, 5 x USB ports, 1 x RJ45, WiFi (option) |
| TOUCH | 10 points PCAP, or metal mesh option |
|
DIMENSION WEIGHT |
2100(H) x 960(W) x 320(D) mm, (w/o basement) 245 Kg approx (without air-con) |
| Waterproof IP65 Enclosure | |
| COOLING | By cooling fans controlled by MCU for outdoor |
| 1200W air-conditioner option for harsh outdoor | |
| FRONT PROTECTION | 3+3 AR vandal glass or 6mm AR vandal glass |
|
ENVIRONMENTAL OPTION |
Operating Temperature -20-45oC, Wide temp. -30-50oC (with cool/warm air-con) |
| Operating Humidity 10%-85% | |
| Storage Temperature -30-60oC | |
| Storage Humidity 5%-90% | |
| WARRANTY | One Year |
Application Of Outdoor LCD Digital Signage
1. Public Places: Subway, Airport, Bookshop, Exhibition hall, Gymnasium, Museum, Conference center, Talent market, Lottery center, etc.
2. Entertainment Places: Movie theatre, Fitness center, Vacational village, KTV bar, Internet bar, Beauty salon, Golf course, etc.
3. Financial Institution: Bank, Security/ Fund/ Insurance company, etc.
4. Business Organizations: Supermarket, Shopping malls, Exclusive shop, chain store, 4S shop, Hotel, Restaurant, travel agency, Chemist's shop, etc.
5. Public Service: Hospital, School, Telecom, Post office, etc.
6. Real Estate&Property: Apartment, Villa, Office building, Commercial office buildings, Model houses, Sales offices, the entrance of elevator, etc.
Advantage Of Outdoor LCD Digital Signage
Sun Readable
1. High brightness, high definition full HD LCD panel;
2. Anti-refiective glass with less than 3%low refiectivity;
3. Low humidity and constant temperature inner system enviroment allows LCD panel to perform optimally;
4. With light sensor, automatically adjust the brightness, environmental friendly and maximum energy saving.
Waterproof
1. Unique patented sealing technology;
2. Outdoor security anti-corrosion more than 5 years;
3. IP65 protection grade enclosure dust can not enter into the display under the 20 mbar pression, harmless when water jetting in ever direction.
Extreme Temperature
Why we were chosen:
1. More than 10 years of professional experience in digital signage manufacturing.
2. LCD items from 6.5 "to 86" in various brightness can be customized according to your specific requirements.
3. The minimum order quantity can meet all your requirements.
4. Modes of transportation: International express, air transportation and sea transportation.
5. Warranty :1 year warranty, lifetime maintenance.
